There is no need to figure this out for yourself.
Tapping the building's main ground normally means clamping a wire to the copper water pipe as a ground or connecting it to a driven ground rod. This is easy for me because my wiring panel (which is only a couple of feet from the electrical box) already has a direct ground connection for other wiring. I prefer to tap directly into the building's main ground. You could run the ground from the ground connector on the power supplyĪnd it will work since this ground will run back to the electrical box and then to the building's main ground. To differentiate the positive and negative wires.įor this alarm, the ground is located at the opposite end of the circuit board. Usually your power wire will be colored, labeled with + or -, or will have a stripe (for power) Connect the + terminals together and the - terminals together. Typically, both the power supply and alarm panel will have power connections The power supply will either have 2 screw terminals (+, -) or 3 terminals (+, -, ground).
Using 18 AWG or better wire, measure the length of wire needed to connect the power supply at the power outlet to the power terminals on the circuit board.įirst connect the wires to the power supply, then the wires to the alarm panel, and then finally plug in the power supply to the electrical outlet. Connect the ground first (black), and then the power (red). The wire colors will be red & black which match perfectly the red and black terminals on the battery itself. Buying the recommended BD7-12 battery or purchasing the battery, power supply, and main board in a kit is easier. In this case, they should both be 12 volt 7 amp-hours. First, verify that the power requirements of the circuit board match those of the battery. View and download dsc 3g3070 installation manual online.For this alarm system, the wires for the battery come directly out of the side of circuit board. Wiring diagrams and explanations for the main panel sensors keypads sirens power and phone for a real dsc alarm system. The pin red and yellow may be inverted the pin number 1 is the red and in the table device 2 is set as 4 the mini molex has the pin 1 in the red wire location. Gesamtliste technics und panasonic ersatzteile. Kt 400 using entrapass ethernet ready encrypted 4 door controller the kt 400 four door controller is a secure and easy to use networked access control solution with support for up to eight entrapass. View and download dsc 3g3070 installation manual online. Kevin the wiring diagram that comes with the 2006c and the 2010c is pretty straightforward. There is a diagram in there that shows the gpsmap 2006c and its wires and also the wires associated with the gps 17 sensor. Lights or a text readout can then give you further information about the problem condition. During a trouble condition the intermittent annoying beeping is intended to make you come to the keypad where you can see the display.
